MAUS cubesat sunsensor

MAUS cubesat sunsensor

3,863

The MAUS is the World’s first radiation hardened analogue fine Sunsensor for Cubesat applications. As the MAUS uses similar diodes and membranes as the BiSon the sensors are extremely radiation tolerant which means that the sensor can also be used for missions beyond low Earth orbit. The use of a standard nano-D connector provides a highly reliable but compact electrical interface thus leading to a height of less than 5mm.

*unit price is dependent on order quantity

Sold By : Lens R&D Category:
  • Features
  • Documents
Temperature range -40°C.. + 80°C
Mass <24 g
Sine Vibration
20 g
Random vibration
19.9g at 2 g² / Hz
Pyro shock 3,500g
Radiation tolerance 8.1014 1 MeV electrons (at bare diode level, equalling 19.2 Mrad TID and 25.109 MeV cm²/g TNID
  • Fine sunsensor for nano-satellite applications
  • Space
  • ITAR free
  • Sales reference: 700S00901
