Oxford Space Systems Deployable Yagi Antenna for AIS and VDES applications

Oxford Space Systems Deployable Yagi Antenna for AIS and VDES applications

135,000

The Oxford Space Systems Yagi antenna unlocks the next generation of AIS and VDES services. The Yagi antenna provides high RF performance for space maritime and vessel tracking applications in VHF-band. From an efficient 1U stowed package it deploys in a single step using strain energy. The current product is a 3-element configuration, but we have 2-element versions as part of the development path. The Yagi antenna deployed length is 900 mm.

Availability: 9 months

*price from 140000$

Vendor: Oxford Space Systems

Description

Features

  • Flight ready
  • High gain
  • Stowage efficient (1U)
  • Low mass and complexity
  • Scalable design
  • Optimised for AIS and VDES applications
  • Directional pattern
  • ITAR-free

Performance

Mechanical dimensions:

– stowed height: 100 mm

– deployed height: 900 mm

– Single-shot passive deployment

RF requirements:

  • Operating frequency range: VHF-band
  • Centre frequency (fc) 159.5 MHz
  • Bandwidth (B) 6 MHz
  • Gain: 6dBi +
  • Dual polarization

Documents

Deployable Yagi antenna brochure

DataSheet upon request

Configurations

The Yagi antenna is operational in the VHF frequency band.
