MT01 Compact Magnetorquer

Flight heritage since 2013

800.00

With only 7.5 grams and 3.2 millimeters thickness, the MT01 Compact Magnetorquer is a vacuum core magnetic coil designed fo ADCS control in cubesat mission from 1U to 3U that boast an impressive performance compared to its small footprint over the mass, power and area budget of the spacecraft. Even with that small dimensions the MT01 is capable of greater magnetic moments, turn speeds and angular accelerations than comparable products on the market, yet the power usage is kept to a minimum: It can turn a 1U mass 90 degrees in 60 seconds using only 0.2 Watts at a LEO orbit of 500kms.

MT01 can be integrated in to our BA0x family of high capacity compact batteries and our DSA Deployable Solar Array family too, the biggest advantage of the MT01 is that it can be easily affixed anywhere on your spacecraft using a minimal area.

Every coil is tested and qualified in our own facilities and shipped with full reports and packed with additional match connectors interfaces.
Availability: 2 weeks

Category:
  • Features
  • Performance
  • Product properties
  • Materials
  • Testing
  • Configurations
  • Documents
  • Low cost, proven standard
  • Very thin and Lightweight: only 3.2 mm thick at 7.5 grams
  • Compact, power efficient, yet powerful magnetic dipole strength: Up to 0.39 Am2
  • Fast 5.90 degrees per second turn speed (at max power, 1U mass) optimizes power usage
  • Perfectly coupled with our DSA Deployable Solar Arrays or BA0x batteries
  • Space heritage from NEE-01 PEGASUS, NEE-02 KRYSAOR and IRVINE01
  • Manufactured with space grade materials according to space standards and custom mission design
  • Functional, performance, thermal bake out and vibration tests provided with documentation.
  • Extensive documentation as 3D pdf, STEP files and blue prints
  • Compatible with almost any structure and compliant to CubeSat Standard
  • Custom Interface available
  • Working Voltage: From 1.25V to 7.5V
  • Working Current: From 100mAh to 2000 mAh
  • Nominal Magnetic moment: >0.19 Am2
  • Saturation Magnetic moment: >0.85 Am2
  • Linearity: +/- 4% across operating design range
  • Residual moment: <0.0045 Am2
  • Torque: 5.36 µNm @ 7.2-3 Tesla (1U mass)
  • Angular acceleration: 3.2-3 Rad/sec-2 (1U mass)
  • B-center = 8.9 Gauss
  • B-corners = 14.5 Gauss
  • Supply Power: From 250mW to 1750mW
  • Typical resistance: 4.1 to 4.7 ohms @ 25°C
  • Random Vibration: 16g rms
  • Lifetime: >10 years
    • Dimensions:
      • External: 50×50 mm
      • Internal: 42×42 mm
      • Width: 4.3 mm
      • Height: 3.2 mm
    • Mass: 7.5 grams
    • Operating Temperature: -55 °C to +85 °C
    • Radiation Tolerance: 2 years minimum in LEO, 4 years minimum when the S/C has NEMEA shielding
    • Pre-evacuated enamel copper wire
    • Cohesion: Space grade epoxy 3M
    • Interfaces:
      • Custom choice, normally Molex PicoBlade/PicoSpox inline 2 pin connector with gold plated contacts
      • PTFE (Teflon) space grade cables, single strand, silver plated copper (AWG26 to AWG30)
  • All coils are provided with tests reports regarding the following tests:
  •

    Test QT AT
    Functional
    Vibration
    Thermal Cycling
    Thermal Vacuum
    Cable/Connector integrity
    Continuity
    Performance
    Freezing/Overheating
  • Thermal Bake out (10E-7 mbar @ 50C for 24 hours)
  • Full vibration test for Dnepr and Long March 2D vibration profiles, other LV profiles available upon request
  • QT and AT is performed on the unit to be shipped at no charge.
  •

    Configuration Price
    MT01 Compact Magnetorquer 50x50x3.2 mm Є 800
    Optional:  Integrated to BA0x High Capacity Battery Array – Є 100
    Optional:  Integrated to DSA Deployable Solar Array – Є 100
    Optional:  Integrated thermal sensor + Є 150
